Engineered for transport efficiency and on-site flexibility. Each unit is easy to assemble and disassemble without compromising structural integrity.
- Sizes from 6000mm to 7938mm in length
- Customizable beam thicknesses and materials for enhanced load-bearing capacity.
Project Parameters
• Product Model: CTR-FA
• Size: 6000mm*2438mm*2591/2791/2991mm
• Steel frame: SGH440, surface treatment: hot dip galvanized + spray coated
• Roof Panel: PU foam integral molding, thickness: 60/70mm
• Floor: 1.8mm thickness PVC+18mm thickness cement fiber board/calcium silicate board
• Wall panel:50/75/100mm sandwich panel, core material: TPS, PU, rockwool
• Power: IEC, CE, UL
• Wind load: 210km/h
• Frame color: Red, blue, medium grey, white grey
• Packaging method: 40ft high cube container/SOC
- Date: June 25, 2025
- Layout 6000mm to 7938mm in length
- Design Code: CTR-D
- Created By: Maya Construction
